Rear fog lamp
Black radiator grill
Front outer mirror power fold
Front wiper intermittent timing adjustable and speed sensing
Headlamps: LED auto-leveling
Front console panel
FM antenna -1

17" Alloys
225/55R17 with 17 x 7-1/2 J silver-colored wheels

Overall length mm 4,870
Overall width mm 1,840
Overall height mm 1,450
Wheelbase mm 2,830
Minimum ground clearance (between axles)
Laden With driver(75kg) mm 125
Unladen mm 165

Air Conditioner with rear vent cooler
Airbag cover (Type A)
Black urethane steering wheel
Front, rear & trunk room lamp incandescent bulb
Shift knob: half heather
Rear center armrest
Side door trim like suede
Sunvisor with vanity mirror, cover & TH
Inner Mirror Day/Night: Manual
Keyless Entry
Power Door Lock switch
Inner Lock Knob_Auto Door Lock (w/ Back-Up Battery)
Door Lock One Touch Release (D&P)
Incandescent lamp glove box illumination

Over Head Console with Sunglass Holder

Fabric seats
Seat Adjustment (Driver): Lifter, Lumbar, slide, reclining (Manual)
Seat Adjustment (Passenger): Slide, reclining (Manual)

AM/FM (ETR), CD(MP3)
Audio (Segment Display)
STD 4 Speakers
Bluetooth (Hands-Free)

SKYACTIV-G 2.0 L
Type In-line, 4-cylinder DOHC, 16-valve<
Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic
Displacement 1,998cc
Compression ratio 13.0:1
Fuel system Direct injection
Recommended fuel type 90–94RON / 95RON or above
Maximum Power 115Kw @6,000 rpm
Horse Power 156 HP
Maximum torque 200Nm @4,000 rpm
Maximum speed with limiter km/h 205
Fuel tank capacity (liters) 62

Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic

Minimum turning radius (kerb-to-kerb) m 5.6

Luggage capacity (excluding underfloor storage space)
With the rear seat in use, up to tonneau cover L 429*
With the rear seat folded, up to tonneau cover L NA
Gross vehicle weight kg 2,019
Fuel capacity (liters) 62

Auto headlamps ON/OFF*
Sunroof*
Headlamps: LED auto-leveling
Rear fog lamp
Black radiator grill
Front outer mirror power auto fold*
Front wiper intermittent timing adjustable and rain-sensing*
Front console panel
FM antenna – 2*
* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

17" Alloys
225/55R17 with 17 x 7-1/2 J silver-colored wheels

Overall length mm 4,870
Overall width mm 1,840
Overall height mm 1,450
Wheelbase mm 2,830
Minimum ground clearance (between axles)
Laden With driver(75kg) mm 125
Unladen mm 165

Air Conditioner with rear vent cooler
Airbag cover (Type A)
Black urethane steering wheel
Front, rear & trunk room lamp incandescent bulb
Shift knob: leather
Rear center armrest with USB*
Side door trim like leather*
Sunvisor with vanity mirror, cover, lamp* & TH
Inner Mirror Day/Night: Auto*
Keyless Entry
Power Door Lock switch
Inner Lock Knob_Auto Door Lock (w/ Back-Up Battery)
Door Lock One Touch Release (D&P)
Incandescent lamp glove box illumination
Navigation with map*
Car Play / Android Auto*

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

Over Head Console with Sunglass Holder

Fabric seats
Seat Adjustment (Driver): Lifter, Lumbar, slide, reclining (Manual)
Seat Adjustment (Passenger): Slide, reclining (Manual)

AM/FM (ETR), CD(MP3)
TFT color + Commander Audio *
STD 6 Speakers*
Bluetooth (Hands-Free)

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

SKYACTIV-G 2.0 L
Type In-line, 4-cylinder DOHC, 16-valve<
Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic
Displacement 1,998cc
Compression ratio 13.0:1
Fuel system Direct injection
Recommended fuel type 90–94RON / 95RON or above
Maximum Power 115Kw @6,000 rpm
Horse Power 156 HP
Maximum torque 200Nm @4,000 rpm
Maximum speed with limiter km/h 205
Fuel tank capacity (liters) 62

Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic

Minimum turning radius (kerb-to-kerb) m 5.6

Luggage capacity (excluding underfloor storage space)
With the rear seat in use, up to tonneau cover L 429*
With the rear seat folded, up to tonneau cover L NA
Gross vehicle weight kg 2,019
Fuel capacity (liters) 62

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

Automatic on/off headlights
LED fog lights
LED Daytime Running Lights
Rain-sensing variable-intermittent windshield wipers
Exterior mirror with power adjustment and auto-folding

16 x 5.5 J aluminum alloy
185/60 R16
Temporary spare tire - T125/70 D15

Wheelbase (mm) 2,570
Track, front (mm) 1,495
Track, rear (mm) 1,485
Length (mm) 4,320
Width (mm) 1,695
Height (mm) 1,470
Minimum ground clearance, unladen (mm) 150

Air conditioning climate control
Power windows with driver's one-touch down/up feature
Cruise control with steering-wheel-mounted controls
Mazda Advanced Keyless Entry
Push Button Start
Tilt & telescopic steering column

Front cup holder
Front door storage pockets with bottle holders
Front passenger-side seatback pocket

5-passenger seating capacity
60/40 split fold-down rear seatback
Seat trim Leather/synthetic
Carpet floor mats Leather-wrapped steering wheel and shifter

7" full-color touch screen display
6 speaker audio system
Bluetooth® hands-free phone and audio streaming capability

MAZDA CONNECT™ Infotainment System
- Multifunction Commander Control
- Infotainment system voice command
- Radio Broadcast Data System program information
- Aha™ internet radio integration
- Stitcher™ internet radio integration

Auxiliary audio input jack
USB Audio input, 2 in front center console
Steering wheel-mounted audio controls

Full-color active driving display
Electronic odometer
Trip computer

Engine type SKYACTIV®-G 1.5L DOHC S-VT petrol engine with i-stop
Maximum power 81kW @ 6,000rpm / Horsepower 108.6 hp @ 6,000rpm<
Maximum torque 141Nm @ 4,000rpm / Maximum torque 103.9 lb-ft @ 4,000rpm
Displacement (cc) 1,496
Bore x stroke (mm) 74.5 x 85.8mm
Compression ratio 13.0 : 1 Fuel system Advanced Direct Injection Recommended fuel
Regular unleaded (91RON or higher) or E10
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

Type Front-wheel drive (FWD)
Manual Transmission SKYACTIV®-MT 6-speed overdrive
Automatic Transmission SKYACTIV®-DRIVE 6-speed automatic transmission with manual-shift
i-stop standard

Gear ratios (:1) 6 AT
1st 3.529
2nd 2.025
rd 1.348
4th 1.000
5th 0.742
6th 0.594
Reverse 2.994
Final Drive 4.319

6 MT
1st 3.583
2nd 1.904
3rd 1.290
4th 0.972
5th 0.795
6th 0.645
Reverse 3.454
Final Drive 4.105

Brakes 4-wheel disc
- Front 258-mm vented disc
- Rear 200-mm solid disc
- ABS 4-wheel, 4-channel with Electronic Brake Force Distribution and Brake Assist
Steering type Power rack-and-pinion with variable assist
Power assist Electronic Power Assist Steering (EPAS)
Turning circle diameter, curb-to-curb (m) 9.8m
Suspension 4-wheel independent
- Front MacPherson strut with stabilizer bar
- Rear Multilink with stabilizer bar

Curb weight (kg) 1,046 (MT) / 1,076 (AT)
Fuel capacity (liters) 44

Auto headlamps ON/OFF*
Front & rear combination signature illumination*
Sunroof*
Headlamps: LED auto-leveling
Rear fog lamp
Black radiator grill
Front outer mirror power auto fold*
Front wiper intermittent timing adjustable and rain-sensing*
Front console panel
FM antenna – 2*
* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

19" Alloys
225/45R19 with 19 x 7-1/2 J bright colored wheels

Overall length mm 4,870
Overall width mm 1,840
Overall height mm 1,450
Wheelbase mm 2,830
Minimum ground clearance (between axles)
Laden With driver(75kg) mm 125
Unladen mm 165

Air Conditioner with rear vent cooler
Airbag cover (Type A)
Bright leather steering wheel
Front console decoration panel vinyl leather*
Meter set with multi Dot Display*
Headup display on windscreen*
Front, rear & trunk room lamp incandescent bulb
Shift knob: leather
Rear center armrest with USB*
Side door trim like leather*
Sunvisor with vanity mirror, cover, lamp* & TH
Inner Mirror Day/Night: Auto*
Smart Keyless, Front back door & trunk*2
Power Door Lock switch
Inner Lock Knob_Auto Door Lock (w/ Back-Up Battery)
Door Lock One Touch Release (D&P)
Incandescent lamp glove box illumination
Navigation with map*
Car Play / Android Auto*

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

Over Head Console with Sunglass Holder

Leather seats *
Memory seat adjustments for driver*
Driver & passenger front seat ventilation*
Seat Adjustment (Driver): Lifter, Lumbar, slide, reclining (Power) *
Seat Adjustment (Passenger): Lifter, Slide(memory & power), reclining (power)

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

AM/FM (ETR), CD(MP3)
TFT color + Commander Audio
BOSS 11 Speakers *
Bluetooth (Hands-Free)

SKYACTIV-G 2.5 L
Type In-line, 4-cylinder DOHC, 16-valve<
Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic
Displacement 2,488cc
Compression ratio 13.0:1
Fuel system Direct injection
Recommended fuel type 90–94RON / 95RON or above
Maximum output Kw 140/6,000 *
Horse Power HP 190 *
Maximum torque 252/4,000 *
Maximum speed with limiter km/h 221 *
Fuel tank capacity (liters) 62

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic

Minimum turning radius (kerb-to-kerb) m 5.6

Luggage capacity (excluding underfloor storage space)
With the rear seat in use, up to tonneau cover L 429*
With the rear seat folded, up to tonneau cover L NA
Gross vehicle weight (GVW) kg 2,034 *
Fuel capacity (liters) 62

Auto headlamps ON/OFF*
Front & rear combination signature illumination*
Sunroof*
Headlamps: LED auto-leveling
Rear fog lamp
Black radiator grill
Front outer mirror power auto fold*
Front wiper intermittent timing adjustable and rain-sensing*
Front console panel
FM antenna – 2*
* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

19" Alloys
225/45R19 with 19 x 7-1/2 J bright colored wheels

Overall length mm 4,870
Overall width mm 1,840
Overall height mm 1,450
Wheelbase mm 2,830
Minimum ground clearance (between axles)
Laden With driver(75kg) mm 125
Unladen mm 165

Air Conditioner with rear vent cooler
Airbag cover (Type A)
Bright leather steering wheel with stitch *
Front console decoration panel vinyl leather*
Multi Digital 7" inch Display
Meter set with multi Dot Display*
Headup display on windscreen*
Front, rear & trunk room lamp LED
Driver and passenger front foot lamp *
Shift knob: leather
Rear center armrest with USB
Side door trim like leather
Sunvisor with vanity mirror, cover, LED lamp* & TH
Inner Mirror Day/Night: Auto*, frameless
Smart Keyless, Front back door & trunk*2
Power Door Lock switch
Inner Lock Knob_Auto Door Lock (w/ Back-Up Battery)
Door Lock One Touch Release (D&P)
LED lamp glove box illumination
Glove box flock lining, coin box flock lining & console flock lining with bright knob *
Navigation with map
Car Play / Android Auto
Side door lamp, door pocket lamp: equipped front & rear *
* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

Over Head Console with Sunglass Holder

Leather seats *
Memory seat adjustments for driver*
Driver & passenger front seat ventilation*
Seat Adjustment (Driver): Lifter, Lumbar, slide, reclining (Power) *
Seat Adjustment (Passenger): Lifter, Slide(memory & power), reclining (power)

AM/FM (ETR), CD(MP3)
TFT color + Commander Audio
BOSS 11 Speakers *
Bluetooth (Hands-Free)

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

SKYACTIV-G 2.5 L Turbo
Type In-line, 4-cylinder DOHC, 16-valve<
Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic
Displacement 2,488cc
Compression ratio 10.5:1
Fuel system Direct injection
Recommended fuel type 90–94RON / 95RON or above
Maximum output Kw 170/5,000 *
Horse Power HP 258 *
Maximum torque 420 NM @2,000 * rpm
Maximum speed With limiter km/h 239 *
Fuel tank capacity (liters) 62

* Unique / Additional features

Important Note –
• Some of the specifications may vary from the actual car model available in the showroom
• All the specifications are as per Bahrain market

Drivetrain FWD (Front Wheel Drive)
TRANSMISSION SKYACTIV-DRIVE 6-speed automatic

Minimum turning radius (kerb-to-kerb) m 5.6

Luggage capacity (excluding underfloor storage space)
With the rear seat in use, up to tonneau cover L 429*
With the rear seat folded, up to tonneau cover L NA
Gross vehicle weight (GVW) kg 2,034 *
Fuel capacity (liters) 62
